Tensor Regression with spgtr() • tensory

library(tensory)
#>
#> Attaching package: 'tensory'
#> The following object is masked from 'package:stats':
#>
#>     reshape
#> The following object is masked from 'package:utils':
#>
#>     find
#> The following object is masked from 'package:methods':
#>
#>     kronecker
#> The following objects are masked from 'package:base':
#>
#>     %*%, kronecker, scale

Array-valued predictors

Every subject contributes a whole array of numbers rather than a handful of variables:

an image, or a slice of one;
a brain connectivity matrix (region by region);
a spectrogram, or any sensor-by-time grid;
a spatial grid measured at several time points.

Alongside the array each subject has one outcome: a diagnosis (yes/no), a count, a score.

Flattening the array and running glm() does not work. A modest 60 × 60 image is 3,600 predictors; with 300 subjects, ordinary logistic regression has no unique solution and any answer it produces is noise. Flattening also throws away the grid structure: column 12 of row 4 is no longer a neighbour of column 13 of row 4.

spgtr() fits the model on the array as it stands and returns coefficients in the same shape, so they can be looked at the way the data are looked at. Adding a sparsity penalty makes it also select: whole rows, columns, or slices that carry no signal are dropped, and the survivors are reported.

Data layout

Two input shapes are accepted, whichever is more convenient:

A list, X[[i]] being subject i’s matrix or array. All subjects must share the same shape.
One big array of order m + 1, with subjects in the last dimension, e.g. dim(X) == c(8, 6, 120) for 120 subjects measured on an 8 × 6 grid.

The outcome y is a plain vector with one entry per subject: 0/1, TRUE/ FALSE, or a two-level factor for yes/no outcomes; counts for poisson(); any numbers for gaussian().

The simulation below has 200 subjects measured on an 8 × 6 grid where only the top-left corner drives a yes/no outcome.

set.seed(1)
n <- 200
p <- c(8, 6)

B_true <- matrix(0, p[1], p[2])
B_true[1, 1:2] <- c(2, 1.5) # only two cells carry signal

X <- lapply(seq_len(n), function(i) matrix(rnorm(prod(p)), p[1], p[2]))
eta <- vapply(X, function(xi) sum(B_true * xi), numeric(1))
y <- rbinom(n, 1, 1 / (1 + exp(-eta)))

length(X)
#> [1] 200
dim(X[[1]])
#> [1] 8 6
table(y)
#> y
#>   0   1
#>  96 104

Quick start

One call fits the model. u is the number of directions kept per dimension; leave it out and it is chosen for you.

fit <- spgtr(X, y, u = c(1, 1))
fit
#> <spgtr: sparse partial generalized tensor regression>
#> Outcome:         binomial with logit link
#> Subjects:        200
#> Array shape:     8 x 6
#> Directions (u):  1 1
#> Basis:           envelope (lambda = 0)
#> Slices kept:     8/8  6/6
#> Deviance:        183.575

summary() reports what was kept and how well the model fits.

summary(fit)
#> <spgtr: sparse partial generalized tensor regression>
#> Outcome:         binomial with logit link
#> Subjects:        200
#> Array shape:     8 x 6
#> Directions (u):  1 1
#> Basis:           envelope (lambda = 0)
#> Slices kept:     8/8  6/6
#> Deviance:        183.575
#>
#> Slices used, by dimension:
#>   dim 1 (8): all
#>   dim 2 (6): all
#>
#> Deviance explained: 33.7% (in-sample)
#> Coefficient array norm: 1.972
#> Accuracy: 0.765    AUC: 0.859  (in-sample)

The estimated coefficient array has exactly the shape of one subject’s data. Large entries are the cells that push the outcome up or down.

B_hat <- as.tensor(coef(fit))$as_array()
round(B_hat, 2)
#>       [,1]  [,2]  [,3]  [,4]  [,5]  [,6]
#> [1,]  1.32  1.17 -0.23 -0.17 -0.13 -0.21
#> [2,]  0.03  0.03 -0.01  0.00  0.00 -0.01
#> [3,] -0.39 -0.35  0.07  0.05  0.04  0.06
#> [4,]  0.30  0.26 -0.05 -0.04 -0.03 -0.05
#> [5,]  0.15  0.14 -0.03 -0.02 -0.02 -0.02
#> [6,] -0.23 -0.20  0.04  0.03  0.02  0.04
#> [7,]  0.08  0.07 -0.01 -0.01 -0.01 -0.01
#> [8,] -0.14 -0.12  0.02  0.02  0.01  0.02

op <- par(mfrow = c(1, 2), mar = c(2, 2, 2, 1))
image(t(B_true[nrow(B_true):1, ]), main = "truth", axes = FALSE)
image(t(B_hat[nrow(B_hat):1, ]), main = "spgtr estimate", axes = FALSE)

True and estimated coefficient grids side by side

par(op)

Predictions come in three flavours.

head(predict(fit, type = "response")) # probabilities
#> [1] 0.69443758 0.32718356 0.07418792 0.10086653 0.30842322 0.83967336
head(predict(fit, type = "class")) # 0/1 labels
#> [1] 1 0 0 0 0 1
head(predict(fit, type = "link")) # log-odds
#> [1]  0.8209482 -0.7209512 -2.5240700 -2.1876333 -0.8075013  1.6557998

New subjects go in exactly like the training data:

X_new <- lapply(1:3, function(i) matrix(rnorm(prod(p)), p[1], p[2]))
predict(fit, X_new, type = "response")
#> [1] 0.45290830 0.70069007 0.01225726

Choosing how much to compress

u[k] is how many directions are kept in dimension k. Small values mean a simpler, more stable model; larger values mean more flexibility and more parameters — the model has prod(u) coefficients after compression, so u = c(2, 2) costs four.

Omit u and an eigenvalue-ratio rule picks it:

auto <- spgtr(X, y)
auto$u
#> [1] 1 1

To choose by predictive performance instead, fit a few and compare on held-out subjects:

train <- 1:150
test <- 151:200
sapply(1:3, function(k) {
  f <- spgtr(X[train], y[train], u = c(k, k))
  pred <- predict(f, X[test], type = "response")
  mean((y[test] - pred)^2) # Brier score, lower is better
})
#> [1] 0.2316578 0.2397944 0.2511882

Selecting which parts of the array matter

Setting lambda > 0 adds a penalty that removes entire rows and columns of the array. fit$selected lists what survived in each dimension.

sparse <- spgtr(X, y, u = c(1, 1), lambda = 4)
sparse$nonzero # kept per dimension, out of 8 and 6
#> [1] 1 1
sparse$selected
#> [[1]]
#> [1] 1
#>
#> [[2]]
#> [1] 1

Cross-validation chooses lambda without guesswork. spgtr_cv() fits the whole path in every fold, scores each value by held-out deviance, and refits at the winner.

set.seed(2)
cvfit <- spgtr_cv(X, y, u = c(1, 1), nfolds = 5, nlambda = 12)
cvfit$lambda_min
#> [1] 0.05522515
head(cvfit$cv)
#>        lambda deviance
#> 1 0.001275773 42.28004
#> 2 0.001939061 41.97822
#> 3 0.002947200 41.68458
#> 4 0.004479482 41.44865
#> 5 0.006808415 41.40233
#> 6 0.010348186 41.07678
cvfit$selected
#> [[1]]
#> [1] 1
#>
#> [[2]]
#> [1] 1 2

plot(cvfit$cv$lambda, cvfit$cv$deviance, type = "b", log = "x",
     xlab = "lambda (sparsity)", ylab = "cross-validated deviance")
abline(v = cvfit$lambda_min, lty = 2)

Cross-validated deviance against the sparsity level

The selected model uses only a few rows and columns of the array.

round(as.tensor(coef(cvfit))$as_array(), 2)
#>      [,1] [,2] [,3] [,4] [,5] [,6]
#> [1,] 1.97 1.63    0    0    0    0
#> [2,] 0.00 0.00    0    0    0    0
#> [3,] 0.00 0.00    0    0    0    0
#> [4,] 0.00 0.00    0    0    0    0
#> [5,] 0.00 0.00    0    0    0    0
#> [6,] 0.00 0.00    0    0    0    0
#> [7,] 0.00 0.00    0    0    0    0
#> [8,] 0.00 0.00    0    0    0    0

lambda selects whole slices, not individual cells. If row 3 is kept, every cell in row 3 can be non-zero. That is the right notion when rows and columns are meaningful units (brain regions, sensors, time points).

Ordinary covariates

Age, sex, batch, and similar variables belong in Z. They enter the model linearly, are never compressed, and are never penalized.

Z <- cbind(age = rnorm(n), male = rbinom(n, 1, 0.5))
fit_z <- spgtr(X, y, u = c(1, 1), Z = Z)
fit_z$gamma # one coefficient per column of Z
#> [1] -0.1344264  0.1116741

When a fit uses Z, prediction needs it too:

head(predict(fit_z, X, Z, type = "response"))
#> [1] 0.69592784 0.26994530 0.06780515 0.07443153 0.29310962 0.83634716

Outcomes other than yes/no

Pass any GLM family.

counts <- rpois(n, exp(1 + eta / 3))
fit_pois <- spgtr(X, counts, u = c(1, 1), family = poisson())
head(predict(fit_pois, type = "response"))
#> [1] 2.4679801 1.7676270 1.0179056 0.8112382 2.0097816 4.5968332

scores <- eta + rnorm(n, sd = 0.5)
fit_gauss <- spgtr(X, scores, u = c(1, 1), family = gaussian())
cor(predict(fit_gauss), scores)
#> [1] 0.9290174

For a continuous outcome with no sparsity there is also tepls(), the classical tensor envelope PLS estimator; spgtr(..., family = gaussian(), basis = "simpls") reproduces it exactly.

a <- tepls(X, scores, u = c(1, 1))
b <- spgtr(X, scores, u = c(1, 1), family = gaussian(), basis = "simpls")
max(abs(as.vector(a$coef$as_array()) - b$bvec))
#> [1] 8.841083e-11

Out-of-sample evaluation

Everything summary() prints is in-sample and therefore optimistic. Split the subjects, or read the cross-validated deviance from spgtr_cv().

set.seed(3)
idx <- sample(n, 150)
f <- spgtr_cv(X[idx], y[idx], u = c(1, 1), nfolds = 5, nlambda = 8)
prob <- predict(f, X[-idx], type = "response")
yy <- y[-idx]

mean((prob > 0.5) == (yy == 1)) # accuracy
#> [1] 0.72
n1 <- sum(yy == 1); n0 <- sum(yy == 0)
(sum(rank(prob)[yy == 1]) - n1 * (n1 + 1) / 2) / (n1 * n0) # AUC
#> [1] 0.7864583

How the fit is computed

Each dimension of the array is compressed down to a few directions, the generalized linear model is fitted on the compressed predictor, and the fitted coefficients are expanded back to the shape of the original array. The directions come from a closed-form deflation with basis = "simpls" and from an iterative envelope refinement with basis = "envelope". Sun et al. give the derivation.

Performance notes

The two expensive steps — the mode-wise covariances and the manifold solver — are compiled kernels calling BLAS/LAPACK directly, and the score computation reuses the package’s compiled ttm(). Reference implementations in R are used automatically if the package was built without compilation; the two paths agree to numerical tolerance and are checked against each other in the test suite.

A single spgtr() fit on a 60 × 60 predictor with 300 subjects takes about a tenth of a second; the full spgtr_cv() path (20 penalties, 5 folds) takes a second or two.
Cost grows linearly in the number of subjects and in the total array size, and cubically in each individual dimension p_k (from the eigen problems), so a 200 × 200 dimension is far more expensive than four dimensions of 50.
basis = "simpls" skips all iteration and is the fastest option when you do not need sparsity.
spgtr_cv() computes covariances once per fold and warm-starts each penalty from the previous one, so a 20-point path costs far less than 20 separate fits.

Reference

Sun, D., Peng, L., Qiu, Z., Stevens, J., Manatunga, A. and Guo, Y. Sparse partial generalized tensor regression with application to neuroimaging data. Submitted.
Zhang, X. and Li, L. (2017). Tensor envelope partial least-squares regression. Technometrics 59(4), 426–436.
Xiao, N., Liu, X. and Yuan, Y. (2021). Exact penalty function for L21 norm minimization over the Stiefel manifold. SIAM Journal on Optimization 31(4), 3097–3126.
